| Hardware |
|
| Processor / Cores |
MSD6886NQHAT-8-00GG/ 4 |
| Dual Tuner |
No |
| Colour (Front bezel, rear, stand) |
Black / Black / Black |
| Speakers mounted in enclosure |
Yes |
| Mains power switch |
No |
| Swivel base |
No |
| Compact packaging |
Yes |
| Maximum time delay Power On to sound an image |
sec |
| Hotel Lock |
|
| Protected Hotel lock submenu |
Fixed code |
| Clone function for programs, sound and image settings |
Yes |
| Sub-menu lock, including tuning lock |
Yes |
| Keyboard lock |
Yes |
| Maximum volume lock |
Yes |
| Power on volume |
Yes |
| Power on, apply default sound/image settings |
Yes |
| Power on source selection |
Yes |
| Power on RF channel selection |
Yes |
| Power on mode (On / Standby / Last) |
Yes / Yes / Yes |
| Inputs access (Enable / Disable) |
Yes |
| USB Media Player |
|
| Personal Video Recorder |
Yes |
| Time Shift |
Yes |
| DTV Recording |
EPG scheduling, Start from Standby |
| DivX decoder |
No |
| MPEG4 H.264 / H.265 Decoder |
Yes / Yes |
| DMP – Digital media player content |
Music, Photos, Video |
| DMP Auto-play |
Yes |
| DMP for UHD content via USB |
Yes |
| DMP File allocation table |
FAT, FAT32, NTFS |
| PVR File allocation table |
FAT, FAT32, NTFS |
| Image processing |
|
| Backlight control |
Yes |
| Light sensing |
No |
| Dynamic backlight control |
Yes |
| Local dimming / controllable zones |
No |
| Zoom function settings |
16:9, 4:3, Auto, Zoom 1, Zoom 2 |
| 1:1 Pixel mapping |
Yes |
| HDR – High Dynamic Range for luminance |
DMP, HDMI, Netflix |
| HDR system |
HDR10 |
| HLG |
Yes |
| HEVC (H.265) decoder |
Yes |
| Dual image |
No |
| MEMC |
No |
| Analogue TV Reception |
|
| Colour-Sound systems in VHF band |
PAL B |
| Colour-Sound systems in UHF band |
PAL B |
| Stereo sound decoder (Analogue) |
A2, NICAM |
| Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX (Analogue) |
Yes / Yes / Yes |
| Subtitles (Analogue) |
Yes |
| Digital TV Reception |
|
| Television system |
DVB-T, DVB-T2 |
| Video decoder (MPEG2 / MPEG 4) |
MPEG2, MPEG4 |
| AC3 Surround sound decoder |
Yes |
| AS 4599.1 Compliance |
Yes |
| AS 4933.1 Compliance |
Yes |
| LCN – Logical channel number & DTV Service name support |
Yes |
| Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX |
Yes / Yes / Yes |
| Subtitles |
Yes |
| RF Signal strength indicator |
Yes |
| RF Signal quality indicator |
Yes |
| RF Bit error rate indicator |
Yes |
| EPG – Electronic Programming Guide, 7 days for all services |
Yes |
| Audio description (vision impairment aid) |
Yes |
| Parental rating lock |
Yes |
| Smart TV |
|
| Ethernet RJ45 port |
1 |
| Wi-Fi protocols IEEE 802.11 [b, g, n, ac, ad, ..] |
b, g, n |
| Wi-Fi bands |
2,4 GHz |
| Network Streaming (DLNA) |
Yes |
| Bluetooth |
Yes |
| Bluetooth Version |
5 |
| Anyview Cast |
Yes |
| UHD (4k) streaming |
Yes |
| Installed Apps |
AccuWeather, Anyview Cast, BOLT+, DEOD, DStv Now, E-manual, Filmbox, FITE, Game Center, Kidoodle TV, Media, mindset, Netflix, Plex, Prime Video (Amazon), Redbull TV, SHOWMAX, Toon Goggles, TV Browser, VIDAA Art, VIDAA Free, Viu, YouTube, YouTube Kids, YuppTV |
| Freeview Plus – HbbTV 2.0 |
Yes |
| Web browser |
Odin 2.10 |
| Eco & Power Supply |
|
| Power Consumption (Stand-by) |
< 0.5 W |
| Voltage |
100 – 240V |
| Frequency |
50 – 60Hz |
| Functions |
|
| Smartphone app |
Yes |
| Safety and Regulation |
|
| CB |
Yes |
| EMC |
Yes |
| HDMI |
Yes (Hisense internal test) |
| RoHS |
No |
| Accessories |
|
| Remote Batteries |
AAA x 2 |
| User Manual |
Yes |
| Quick Start Page |
Yes |
| Stand area |
1236 × 275mm |
| Wall mount dimensions |
300 x 200 mm |
| Wall mount, screw thread |
M6 |
| VESA compliance |
Yes |
| Detachable power cord |
No |
| Power cord length |
155 cm |
| Remote controller (Technology / Part number) |
IR / EN2J30H |
| Warranty |
In separate sheet |
| Weight & Dimensions |
|
| Carton box dimensions (W x H x D) |
1629 × 996 × 186mm |
| Dimensions with stand (W x H x D) |
1448 × 898 × 275mm |
| Dimensions without stand (W x H x D) |
1448 × 834 × 81mm |
| Net weight (with stand / without stand) |
17 / 16.7kg |
| Connectivity |
|
| HDMI inputs |
3 |
| HDMI1 |
ARC, HDMI 2.0, HDMI type 4K@60Hz with HDCP version 2.2 |
| HDMI2 |
HDMI 2.0, HDMI type 4K@60Hz with HDCP version 2.2 |
| HDMI3 |
HDMI 2.0, HDMI type 4K@60Hz with HDCP version 2.2 |
| Radio frequency input |
1 |
| AV Input |
1 |
| USB (2.0) |
2 |
| S/PDIF Output |
1 |
| Earphone jack |
1 |
| Ethernet RJ45 port |
1 |
| Features |
|
| On / Off timer |
Yes |
| Power off if no signal |
Yes |
| Sleep timer |
Yes |
| Program lock |
Yes |
| OSD transparency control |
No |
| User Interface (UI) |
VIDAA U4 |
| Software version OSD indication |
Yes |
| Legal requirements |
Acceptance of Terms, Disclaimer |
| Favourite channel list |
Yes |
| Electronic point of sales (E-POS) |
Yes |
| OTA – Over the air software updates |
Yes |
| Voice command |
No |
| Screen mirroring |
Anyview Cast |
| Smartphone app |
Yes |
| Replaceable demo video for Store mode |
Yes |
| Remote control via serial port |
No |
| Internet |
|
| Installed Apps |
AccuWeather, Anyview Cast, BOLT+, DEOD, DStv Now, E-manual, Filmbox, FITE, Game Center, Kidoodle TV, Media, mindset, Netflix, Plex, Prime Video (Amazon), Redbull TV, SHOWMAX, Toon Goggles, TV Browser, VIDAA Art, VIDAA Free, Viu, YouTube, YouTube Kids, YuppTV |
| Web browser |
Odin 2.10 |
| Anyview Cast |
Yes |
| Sound |
|
| Audio Power Output (p/ch) |
10 W |
| Number of speakers (Tweeter / Midrange / Woofer) |
0 / 1 / 0 |
| Automatic volume level (AVL) |
Yes |
| Audio equalizer |
Yes |
| Audio enhancement – Type [SRS, BBE, SAP, DBX-TV…] |
DTS Studio sound |
| Lip-sync adjustment |
Yes |
| Dolby Digital |
Yes |
| Technical Details |
|
| Resolution (DPI) |
3840 x 2160 |
| HDMI-CEC Support |
Yes |
| MHL Support |
No |
| Network Streaming (DLNA) |
Yes |
| Wide Colour Gamut |
No |
| MEMC |
No |
| HLG |
Yes |
| Basic Information |
|
| Resolution (DPI) |
3840 x 2160 |
| Display Technology |
LCD / LED lit, UHD |
| RoHS |
No |
| User Interface (UI) |
VIDAA U4 |
| Active display area dimension |
1428,48 x 803,52 mm |
| Screen size (rounded to nearest integer) |
164 cm, 65″ |
| Backlight source |
LED Matrix |
| Display Colour depth |
8bit+FRC |
| Image refresh frequency |
60Hz |
| Smooth motion rate |
120 |
| Maximum brightness of white |
360 cd/m2 |
| Native contrast ratio |
4000 : 1 |
| Viewing Angle (Horiz / Vert) |
178 / 178 Degrees |
| Quantum dot |
No |
| Wide Colour Gamut |
No |
| UHD Premium |
No |
| Response Time |
6,5 ms |
